Description
Simrad AD80 Analoge aandrijfinterface. Drive-interface voor analoge of proportionele regeling van roer of boegschroef met behulp van analoge spanning of laag-niveau stroom met mogelijkheid voor frequentie, spanning of stroomhoek feedback, digitale drive handshake en externe modus ingang.
Specificaties Simrad AD80 Analoge aandrijfinterface:
- Drive output Analog +/- 10V or 4-20mA
- Engine Drive systems integration Analog +/- 10V or 4-20mA
- Rudder sensor support RF300, RF45X, RF25N, RF70, RF14XU
- NMEA 2000 1x CAN terminal, 1 LEN
- Power Consumption, max. 200mA (from CAN)
- Power Consumption, typical 0,1A
- Recommended Fuse Rating Internal fuse 5A
- Supply Voltage 12-16V via CAN
- Operating Temperature Range -15 to +55C (5 to 131F)
- Storage Temperature Range -30C to +70C (-22F to +158F)
- Waterproof rating IPx2
- Compass Safe Distance – Metric, imperial 1 m (39,37″)
- Dimensions (W x H x D) 211 x 167 x 60mm. (8,29 x 6,58 x 2,36″)
- Mounting Type Bulkhead
- Weight 0,5 kg (1,1 lbs)
- Warranty Period 2 years
